Description
P7 is a new generation access control device of Anviz. The P7 adopts touch activation technologies in fingerprint sensor and keypad easy for user operation. As an access control, which are designed with PoE communication and access interface separation, make the P7 easy for Installation and cost down the labor. The powerful access control function is indispensable for P7. Relay output for door control, Wiegand output and group, time zones. Multi-communication with TCP/IP, RS485 and Mini USB port. The Alarm push function will protect access control safe.
-
Features
- Â Â Â Â Using Anviz intelligent core algorithm
-
5000 Fingerprints, 5000 Cards, 50000 Records
-
Optical waterproof fingerprint collection device, abrasion resistance, adapt to all kinds of fingerprints
-
Touch activation fingerprints sensor and keypad
-
Support POE power supply for both device and lock
-
RS485, mini USB and TCP/IP communications, Wiegand output
-
Directly controlled door lock, grouping management, time setting
-
Tamper alarm door magnetic signal interface (known the door open and close state), to support himself back
-
 Fingerprint, password and card combination of independence and recognition
-
 Touch the bright background number keys
-
High precision OLED displays
-
 Standard EM the RFID card reader module, optional Mifare module
-
Optional waterproof cover, realize outdoor use, IP53
-
 Software support for period of time, group management, 16 group access permissions, flexible control
-
32 entrance guard time real-time monitoring data, easy to learn and easy to use
-
-
Specification
Capacity Fingerprint Capacity 5,000 Card Capacity 5,000 Log Capacity 50,000 Interface Comm RS485, Mini USB Slave, TCP/IP, Wiegand Out&In Relay Relay Output (COM, NO, NC or Direct Lock Control) Feature Door Open Sensor Yes Tamper Alarm Yes Card Reader Module EM RFID, Optional Mifare Workcode 6-digits Short Message 50 Hardware PoE Standard IEEE802.3af and IEEE802.3at Operating Voltage DC 12V Size 54(w)*170(h)*41(d)mm Temperature -25℃~70℃ Ingress Protection Rate IP53 (Optional Waterproof Cover) Scan Area 22mm*18mm Resolution 500 DPI Display 128*64 OLED -
Application
